Page: 94
Service Guide ML520/521
Chapter 3 Maintenance & Disassembly
3.2.25 Carriage Shaft
CAUTION
The space motor assembly, etc. may be left in place when removing the carriage shaft. However, use
extra care when doing so.
The carriage cable should be detached from the space motor before removing the carriage shaft.
1. Perform these procedures:
3.2.01
, 3.2.06 , 3.2.07 , and 3.2.16 .
2. Push the end (A) of the carriage shaft (1) until it clears the base frame.
3. Pull the carriage shaft free of the base frame.
4. Remove the support protect reset spring (2).
5. Remove the support protector assembly (3).
6. Remove the frame set carriage (4).
NOTE:
Installation
After installing the carriage shaft, check the printhead gap adjustment.
Refer to Section 3.3
of this Service Handbook.
Cleaning
When cleaning, refer to Section 3.4 of this Service
Handbook.
Lubrication
When lubricating, refer to Section 3.5 of this Service Handbook.
To Next Page
