Omron E5AC-T User Manual

5 - 19
5 Advanced Operations
E5@C-T Digital Temperature Controllers User’s Manual (H185)
5-6 Using the Key Protect Level
5
5-6-2 Entering the Password to Move to the Protect Level
z Initial Setting/Communications Protect
This protect level restricts movement to the Initial Setting Level, Communications Setting Level, and
Advanced Function Setting Level.
z Setting Change Protect
This protect level restricts key operations
z PF Key Protect
This protect level enables or disables PF Key operations.
• The Protect Level can be moved to only by displaying the password display and entering the correct
password. (The user can set any password in the Password to Move to Protect Level parameter.) If no
password is set (i.e., if the password is set to 0 in the Password to Move to Protect Level parameter),
the password input display to move to the Protect Level will not be displayed and the Protect Level
can be moved to directly.
z Password Not Yet Set
• The default is 1.
• The default is OFF.
• The setting change protection indicator ( ) will light when the Setting Change Protect
parameter is set to ON.
• The default is OFF.
5-6-2 Entering the Password to Move to the Protect Level
Move to the Protect Level and set the password.
Example password: 1234
Operating Procedure
1 Press the O and M Keys simultaneously for at least 3 sec-
onds (default) in the Operation Level.
*1
If a password is not set, the Protect Level will be entered and oapt
(Operation/Adjustment Protect) will be displayed.
Protect Level
2 Press the M Key several times in the Protect Level to display
prlp (Password to Move to Protect Level).
1
icpt
Set value Initial Setting Level
Communications
Setting Level
Advanced Function
Setting Level
0 Possible to reach Possible to reach Possible to reach
1 Possible to reach Possible to reach Not possible to reach
2 Not possible to reach Not possible to reach Not possible to reach
off
wtpt
Set value Description
OFF Settings can be changed using key operations.
ON Settings cannot be changed using key operations. (The protect level set-
tings, however, can be changed.)
off
pfpt
Set value Description
OFF PF Key enabled.
ON PF Key disabled (Operation as function key prohibited).
0
oapt
Operation/
Adjustment
Protect
0
prlp
Password to
Move to
Protect Level
