A - 23
A Appendices
E5@C-T Digital Temperature Controllers User’s Manual (H185)
A-6 Parameter Operation Lists
A
A-6-5 Initial Setting Level
A-6-5 Initial Setting Level
Parameters Characters Setting (monitor) value Display Default Unit
Input Type in-t Temperature
input
0: Pt100
1: Pt100
2: Pt100
3: JPt100
4: JPt100
5: K
6: K
7: J
8: J
9: T
10: T
11: E
12: L
13: U
14: U
15: N
16: R
17: S
18: B
19: W
20: PLII
21: 10 to 70°C
22: 60 to 120°C
23: 115 to 165°C
24: 140 to 260°C
5 None
Analog input 25: 4 to 20 mA
26: 0 to 20 mA
27: 1 to 5 V
28: 0 to 5 V
29: 0 to 10 V
5 None
Scaling Upper Limit in-h Scaling lower limit + 1 to 9,999 100 None
Scaling Lower Limit in-l −1,999 to scaling upper limit −1 0 None
Decimal Point dp 0 to 3 0 None
Temperature Unit d-u °C, °F
c, f
°C None
SP Upper Limit sl-h Temperature input: SP lower limit + 1 to Input setting
range upper limit
1300 EU
Analog input: SP lower limit + 1 to scaling upper limit 100
SP Lower Limit sl-l Temperature input: Input setting range lower limit to
SP upper limit − 1
−200 EU
Analog input: Scaling lower limit to SP upper limit − 10
Program Time Unit t-u H-M: Hours and minutes
M-S: Minutes and seconds
h-m
m-s
Hours and
minutes
None
Step Time/Rate of Rise
Programming:
t-pr TIME: Step time programming
PR: Rate of rise programming
time
pr
Step time
programmin
g
None
Time Unit of Ramp
Rate
pru H: Hours
M: Minutes
h
m
Min None
Reset Operation rtsm STOP: Stop control
FSP: Fixed SP operation
stop
fsp
Stop control None
Startup Operation p-on CONT: Continue
RST: Reset
Run: Run
MANU: Manual Mode
cont
rst
run
manu
Continue None
Operation End
Operation
eset RST: Reset
CONT: Continue
FSP: Fixed SP Mode
rst
cont
fsp
Reset None
PV Start pvst SP: SP start (SP priority)
PV: PV start (slope priority)
sp
pv
SP start
All PID AT Upper Limit
SP
tspu SP lower limit to SP upper limit 0 EU
PID ON/OFF cntl ON/OFF 2-PID onof, pid PID None
