Page #279 background image
6 Parameters
6 - 18
E5@C-T Digital Temperature Controllers User’s Manual (H185)
styp
Segment n Format (n = 0 to 31)
The Display Segment Selection parameter must not
be set to END. The Step Time/Rate of Rise
Programming parameter must be set to Rate of
Rise.
This parameter sets the segment type for the specified segment number to ramp, soak, or
step.
z Related Sections
4-7 Setting Programs (page 4-27)
z Related Parameters
Step Time/Rate of Rise Programming (Initial Setting Level): Page 6-59
sp
Segment n SP (n = 0 to 31)
The Display Segment Selection parameter must not
be set to END. The Step Time/Rate of Rise
Programming parameter must be set to Step Time,
or the Step Time/Rate of Rise Programming
parameter must be set to Rate of Rise and the
Segment Type parameter must be set to Ramp or
Step.
This parameter sets the SP for the specified segment number.
For rate of rise programming, the target SP is set.
z Related Sections
4-7 Setting Programs (page 4-27)
z Related Parameters
Step Time/Rate of Rise Programming (Initial Setting Level): Page 6-59
Function
Setting
Setting range Unit Default
ramp (ramp), soak (soak), or step (step) --- ramp
See
See
Function
Setting
Setting range Unit Default
SP lower limit to SP upper limit EU 0
See
See
