Omron E5AZ User Manual

133
Appendix
Sensor Input Setting Ranges
The applicable standards for each of the above input ranges are as follows:
K, J, T, E, N, R, S, B: JIS C1602-1995, IEC 584-1
L: Fe-CuNi, DIN 43710-1985
U: Cu-CuNi, DIN 43710-1985
JPt100: JIS C 1604-1989, JIS C 1606-1989
Pt100: JIS C 1604-1997 IEC 751
Default is set value “5”.
Control Range
• Platinum resistance thermometer and thermocouple input
–20
°C of temperature setting lower limit to +20°C of the temperature setting upper limit
Or, –40
°F of temperature setting lower limit to +40°F of the temperature setting upper limit
• ES1B input
Same as input indication range
• Analog input
–5% to +105% of scaling range
Input type Specifica-
tions
Set
Value
Input Temperature Setting Range Input indication range
Platinum
resistance
thermometer
Pt100 0 −200 to 850 (°C)/−300 to 1500 (°F) −220 to 870 (°C)/−340 to 1540 (°F)
1 −199.9 to 500.0 (°C)/−199.9 to 900.0 (°F) −199.9 to 520.0 (°C)/−199.9 to 940.0 (°F)
2 0.0 to 100.0 (°C)/0.0 to 210.0 (°F) −20.0 to 120.0 (°C)/−40.0 to 250.0 (°F)
JPt100 3 −199.9 to 500.0 (°C)/−199.9 to 900.0 (°F) −199.9 to 520.0 (°C)/−199.9 to 940.0 (°F)
4 0.0 to 100.0 (°C)/0.0 to 210.0 (°F) −20.0 to 120.0 (°C)/−40.0 to 250.0 (°F)
Input type Specifica-
tions
Set
Value
Input Temperature Setting Range Input indication range
Thermocouple K 5 −200 to 1300 (°C)/−300 to 2300 (°F) −220 to 1320 (°C)/−340 to 2340 (°F)
6 −20.0 to 500.0 (°C)/0.0 to 900.0 (°F) −40.0 to 520.0 (°C)/−40.0 to 940.0 (°F)
J7−100 to 850 (°C)/−100 to 1500 (°F) −120 to 870 (°C)/−140 to 1540 (°F)
8 −20.0 to 400.0 (°C)/0.0 to 750.0 (°F) −40.0 to 420.0 (°C)/−40.0 to 790.0 (°F)
T9−200 to 400 (°C)/−300 to 700 (°F) −220 to 420 (°C)/−340 to 740 (°F)
22 −199.9 to 400.0 (°C)/−199.9 to 700.0 (°F) −199.9 to 420.0 (°C)/−199.9 to 740.0 (°F)
E 10 0 to 600 (°C)/0 to 1100 (°F) −20 to 620 (°C)/−40 to 1140 (°F)
L11−100 to 850 (°C)/−100 to 1500 (°F) −120 to 870 (°C)/−140 to 1540 (°F)
U12−200 to 400 (°C)/−300 to 700 (°F) −220 to 420 (°C)/−340 to 740 (°F)
23 −199.9 to 400.0 (°C)/−199.9 to 700.0 (°F) −199.9 to 420.0 (°C)/−199.9 to 740.0 (°F)
N13−200 to 1300 (°C)/ −300 to 2300 (°F) −220 to 1320 (°C)/ −340 to 2340 (°F)
R 14 0 to 1700 (°C)/0 to 3000 (°F) −20 to 1720 (°C)/−40 to 3040 (°F)
S 15 0 to 1700 (°C)/0 to 3000 (°F) −20 to 1720 (°C)/−40 to 3040 (°F)
B 16 100 to 1800 (°C)/300 to 3200 (°F) 0 to 1820 (°C)/0 to 3240 (°F)
Infrared
temperature
sensor ES1B
10 to 70°C 17 0 to 90 (°C)/0 to 190 (°F) −20 to 130 (°C)/−40 to 270 (°F)
60 to
120°C
18 0 to 120 (°C)/0 to 240 (°F) −20 to 160 (°C)/−40 to 320 (°F)
115 to
165°C
19 0 to 165 (°C)/0 to 320 (°F) −20 to 205 (°C)/−40 to 400 (°F)
140 to
260°C
20 0 to 260 (°C)/0 to 500 (°F) −20 to 300 (°C)/−40 to 580 (°F)
Analog input 0 to 50 mV 21 One of following ranges depending on the
results of scaling: −1999 to 9999,
−199.9 to 999.9
−5 to 105% of the setting range
(however, display −1999 to 9999 or
−199.9 to 999.9)
