Setting the SP Upper- and Lower-Limit Values Section 4-6
4-6-2 Setting
To set the set point upper and lower limits, set in the “set point upper limit” and
“set point lower limit” parameters in the “initial setting level”. This example
describes how to set the set point limiter “
−200 to 1300°C” to input type K
thermocouple.
Setting the set point upper limit
Set the “set point upper limit” parameter to “1000”.
1,2,3... 1. Press the key for at least three seconds to move from the “operation
level” to the “initial setting level”.
2. Select “set point upper limit”.
3. Press the or key to set the parameter to “1000”.
Setting the set point lower limit
Set the “set point lower limit” parameter to “−100”.
1,2,3... 1. Select “set point lower limit” in the “initial setting level”.
2. Press the or key to set the parameter to “
−100”.
Set point limiter
Sensor range
−200 1300
1000−100
Operation Procedure
Input type
Set point
upper limit
Initial setting level
in-t
5
sl-h
1300
C
sl-h
1000
C
Operation Procedure
Set point lower
limit
sl-l
-200
C
sl-l
-100
C
