64
Using Event Inputs Section 4-5
When multi-SP is used by
event input
Multi-SP can be used when the option event input unit E53-AZB is mounted
on the E5AZ/E5EZ and “number of multi-SP uses” is set to “1” or “2”.
• When “number of multi-SP uses” is set to “1”
• When “number of multi-SP uses” is set to “2”
Note Event input can be used when the option event input unit
E53-AZB is mounted in the E5AZ/E5EZ. Select event input ON/
OFF while the E5AZ/E5EZ is turned ON. Judgment of event input
ON/OFF is carried out on event inputs of 50 ms or more.
4-5-3 Settings by Key Operation
You can select set points 0 to 3 by changing the set value of the “multi-SP”
parameter. The “multi-SP” display conditions are as follows:
• When the option event input unit E53-AZB is not mounted in the E5AZ/
E5EZ, and “multi-SP” is set to “ON”
• When the option event input unit E53-AZB is mounted in the E5AZ/E5EZ,
the “number of multi-SP uses” is set to “0” and “multi-SP” is set to “ON”
The following table shows the relationship between the “multi SP” parameter
set value and the selected set point.
4-5-4 Settings
To select set points (0/1/2/3)
Before you set the “number of multi SP uses,” cancel protection and move to
the “advanced function setting level”. For details on how to cancel protection,
refer to 4-9 Using the Key Protect Level.
Event input 1 Selected Set Point
OFF Set point 0
ON Set point 1
Event input 1 Event input 2 Selected Set Point
OFF OFF Set point 0
ON OFF Set point 1
OFF ON Set point 2
ON ON Set point 3
Multi-SP Selected Set Point
0Set point 0
1Set point 1
2Set point 2
3Set point 3
Operation Procedure
To Next Page
