Setting the Input Type Section 3-2
3-2 Setting the Input Type
The E5AZ/E5EZ supports four input types: platinum resistance thermometer,
thermocouple, infrared temperature sensor and analog inputs. Set the input
type matched to the sensor used in the “input type” parameter. In the product
specifications, there are models with thermocouple/resistance thermometer
inputs (multi-input) and models with analog input. The settings differ depend-
ing on the model. Check to make sure which model you are using.
3-2-1 Input Type
Setting the input type “thermocouple K −20.0 to 500.0°C”.
1,2,3... 1. Press the key for at least three seconds to move from the “operation
level” to the “initial setting level”.
2. Press the key to enter the set value of the desired sensor. When you
use K thermocouple (
−20.0 to 500.0°C), enter “6” as the set value.
Hint: The set value is fixed if you do not operate the keys on the front panel
for two seconds after changing the parameter, or by pressing the
or key.
List of Input Types
Note The default is “5”.
Operation Procedure
Input type Name Set
Value
Input Temperature Setting Range
Platinum resistance
thermometer
Pt100 0
−200 to 850 (°C)/−300 to 1500 (°F)
1
−199.9 to 500.0 (°C)/−199.9 to 900.0 (°F)
2 0.0 to 100.0 (
°C)/0.0 to 210.0 (°F)
JPt100 3
−199.9 to 500.0 (°C)/−199.9 to 900.0 (°F)
4 0.0 to 100.0 (
°C)/0.0 to 210.0 (°F)
Thermocouple K
5 −200 to 1300 (°C)/−300 to 2300 (°F)
6
−20.0 to 500.0 (°C)/0.0 to 900.0 (°F)
J7
−100 to 850 (°C)/−100 to 1500 (°F)
8
−20.0 to 400.0 (°C)/0.0 to 750.0 (°F)
T9
−200 to 400 (°C)/−300 to 700 (°F)
22
−199.9 to 400.0 (°C)/ −199.9 to 700.0 (°F)
E 10 0 to 600 (
°C)/ 0 to 1100 (°F)
L11
−100 to 850 (°C)/−100 to 1500 (°F)
U12
−200 to 400 (°C)/−300 to 700 (°F)
23
−199.9 to 400.0 (°C)/−199.9 to 700.0 (°F)
N13
−200 to 1300 (°C)/−300 to 2300 (°F)
R 14 0 to 1700 (
°C)/0 to 3000 (°F)
S 15 0 to 1700 (
°C)/0 to 3000 (°F)
B 16 100 to 1800 (
°C)/ 300 to 3200 (°F)
Infrared temperature
sensor
ES1B
10 to 70
°C 17 0 to 90 (°C)/0 to 190 (°F)
60 to 120
°C 18 0 to 120 (°C)/0 to 240 (°F)
115 to 165
°C 19 0 to 165 (°C)/0 to 320 (°F)
140 to 260
°C 20 0 to 260 (°C)/0 to 500 (°F)
Analog input 0 to 50mV 21 One of the following ranges depending on the
results of scaling:
−1999 to 9999, −199.9 to 999.9,
Operation level
25
0
C
Input typ
e
Initial setting level
in-t
5
in-t
6
