Moving to the Advanced Function Setting Level Section 4-8
4-8 Moving to the Advanced Function Setting Level
In the default setting, the advanced function setting level is protected and you
cannot move to this setting level. To move to this setting level, you must first
cancel the protection applied by the “protect level.” See 4-9 Using the Key Pro-
tect Level.
1,2,3... 1. Press the and keys simultaneously for at least three seconds in
the “operation level.”
Note The key pressing time can be changed in ”Move to protect level
time” (advanced function setting level).
2. The controller moves to the protect level, and “operation/adjustment pro-
tect” is displayed.
3. Press the key once to move to “initial setting/communications protect.”
4. Set the set value to “0”
5. Press the and keys simultaneously to return to the “operation lev-
el.”
6. Press the key for at least three seconds to move to the “initial setting
level” from the “operation level.”
7. Select the “Move to advanced function setting level” parameter by pressing
the key.
8. Press the or key to enter the password (“
−169”), and either press
the key or leave the setting for at least two seconds to move to the “ad-
vanced function setting level” from the “initial setting level.”
"operation/
adjustment
protect"
Protect level
oapt
0
icpt
1
icpt
0
25
100
C
in-t
5
amoV
-169
init
off
"initial setting/
communications
protect"
PV/SP
Operation level
Input type
Initial setting level
Move to advanced
function setting
level
Advanced function
setting level
