7.1 Parameter Structure
E5CK
7–3
Ă• Parameters are displayed on the No.1 display, and the process value is
displayed in Hexadecimal on the No.2 display.
Ă• Normally, the process value changes by several digits. The process value
flashes, for example, when a sensor error causes the process value to
stray from the calibration target range.
Ă• When the process value display is flashing, the process value is not stored
as data even if the
key is pressed.
Ă• Once the E5CKĆT controller has been calibrated by the user, [ĂĂ
] is
displayed preceded by the ." mark when the calibration mode is next seĆ
lected.
F Calibration item
menu
Calibration item
parameter
Process value
F Calibration store
mark
Calibration store mark
To Next Page
