6 - 17
6 Parameters
E5@C Digital Temperature Controllers User’s Manual (H174)
6-3 Operation Level
6
v-m
Valve Opening Monitor
A Position-proportional Model must be used.
The PV/SP Display Selection parameter must not
be set to 4.
• This parameter is used to monitor the valve opening for position-proportional control.
• The valve opening can be monitored if a potentiometer is connected and motor calibration
is executed.
Related Parameters
Motor Calibration (Initial Setting Level): Page 6-59
PV/SP Display Selection (Advanced Function Setting Level): Page 6-92
* You can use this selection only with the E5EC-PR@-8@@ or E5AC-PR@-8@@.
(The Digital Controller must be manufactured in August 2014 or later (version 2.2 or higher).)
Control Monitor range Unit
Position-proportional control Measured opening: −10.0 to 110.0 %
Estimated opening*: 0.0 to 100.0 %
To Next Page
