6 - 21
6 Parameters
E5@C Digital Temperature Controllers User’s Manual (H174)
6-4 Adjustment Level
6
cmwt
Communications Writing
Communications must be supported.
The Event Input Assignment 1 to Event Input
Assignment 6 parameters must not be set to
enable/disable communications writing.
• This parameter enables/disables writing of parameters to the E5@C from the host
(personal computer) using communications.
• This parameter is not displayed if the Event Input Assignment 1 to Event Input
Assignment 6 parameters are set to enable/disable communications writing.
• The Communications Writing parameter will be automatically turned ON if the Protocol
Setting parameter is set to component communications, Host Link (FINS)
communications, or the MC Protocol (format 4).
Related Parameters
Communications Setting Level: Page 6-96
Protocol Setting, Communications Unit No., Communications Baud Rate,
Communications Data Length, Communications Parity, and Communications Stop Bits
spmd
SP Mode
There must be a remote SP input.
The ST (self-tuning) parameter must be set to OFF
(default: ON).
The Remote SP Enable parameter must be set to
ON (default: OFF).
The Event Input Assignment parameters must not
be set to SP Mode Switch.
This parameter sets the SP mode. In Local SP Mode, the local SP that is set inside the Dig-
ital Controller is used as the SP. In Remote SP Mode, the remote SP that is specified with
an external signal (e.g., 4 to 20 mA) is used as the SP.
Related Parameters
ST (self-tuning) (Initial Setting Level): Page 6-46
Remote SP Enable (Advanced Function Setting Level): Page 6-85
Setting range Default
ON:
OFF:
Writing enabled
Writing disabled
OFF
Setting range Default
LSP: Local SP and RSP: Remote SP LSP
To Next Page
