6 Digital Input Units
6 - 4
NX-series Digital I/O Unit User’s Manual (W521)
6-2 Specifications of I/O Data
This section describes I/O data for the Digital Input Units.
This section describes the allocable I/O data in the Digital Input Unit.
An I/O entry mapping is assigned to the I/O allocation settings for the Digital Input Unit.
A specific I/O entry is assigned to the I/O entry mapping for each NX Unit model. These allocations are
fixed, so you cannot add others or change them.
An I/O entry means the I/O data described in this section. An I/O entry mapping means a collection of
I/O entries.
To assign the I/O allocation information of the EtherCAT Slave Terminal to an NJ-series CPU Unit, use
the I/O ports for the allocated I/O data.
 Four-point Input Units
6-2-1 Allocable I/O Data
NX Units in Free-Run Refreshing or Synchronous I/O Refreshing
Data name Description
Data
type
Default
value
I/O port
name
Index
Subin-
dex
Input Bit 00 The input value for input
bit 00.
BOOL FALSE Input Bit 00 6000 hex 01 hex
Input Bit 01 The input value for input
bit 01.
BOOL FALSE Input Bit 01 02 hex
Input Bit 02 The input value for input
bit 02.
BOOL FALSE Input Bit 02 03 hex
Input Bit 03 The input value for input
bit 03.
BOOL FALSE Input Bit 03 04 hex
