Omron NX-OD5256 User Manual

8 Digital Mixed I/O Units
8 - 6
NX-series Digital I/O Unit User’s Manual (W521)
*2. The descriptions of Input Filter Mode Setting are as follows.
 Sixteen-point Output Units
Set
value
Setting description Default value Setting range
0 Enable ON Filter and OFF Filter 0 0/1
1 Enable Only OFF Filter
8-3-2 Output Settings
NX Units in Free-Run Refreshing or Synchronous I/O Refreshing
Setting name Description
Default
value
Setting
range
Unit Index
Subin-
dex
Refer-
ence
Load Rejection Output
for Output Bit (16 bits)
Set the output at load OFF
in units of 16 bits.
Bit 0: Setting for output bit
00
Bit 1: Setting for output bit
01
•
•
•
Bit 15: Setting for output
bit 15
FALSE: OFF
TRUE: Hold the present
value.
0000
hex
0000 to
FFFF hex
 5012
hex
01 hex P. 7-12

Omron NX-OD5256 Specifications

General

Brand	Omron
Model	NX-OD5256
Category	I/O Systems
Language	English
