A - 61
Appendices
NX-series Digital I/O Unit User’s Manual (W521)
A-2 Dimensions
A
A-2-2 Connector Types
 Units with MIL Connectors (1 Connector with 20 terminals)
 Units with MIL Connectors (1 Connector with 40 terminals)
A-2-2 Connector Types
30 mm Width
32.1
100 1.51.5
27.85
19.1
16.1
30
71
65.2
89.52
104.5
58.3
(Unit: mm)
38
32.1
19.1
16.1
30
71
65.2
89.52
104.5
83.7
100
1.51.5
(Unit: mm)
