A - 99
Appendices
NX-series Digital I/O Unit User’s Manual (W521)
A-5 List of NX Objects
A
A-5-4 Digital Mixed I/O Units
This object gives the product information.
A-5-4 Digital Mixed I/O Units
Unit Information Objects
Index
(hex)
Subindex
(hex)
Object name
Default
value
Data range Unit
Data
type
Acc
ess
I/O
allo-
cat-
ion
Data
attri-
bute
1000  NX Bus Identity  
00 Number of Entries 7 7  USINT RO Not
pos-
sible

02 Model
*1
*1. The product models are assigned in ascending order from the lowest number of array elements. Any remainder elements
are filled with spaces.
ARRAY
[0..11] OF
BYTE
RO Not
pos-
sible

03 Device Type
*2
*2. The device types are assigned for each product Unit type.
Bits 0 to 31: Device type
UDINT RO Not
pos-
sible

04 Product Code
*3
*3. The product codes are assigned for each product model.
Bits 0 to 31: Product code
UDINT RO Not
pos-
sible

05 Vendor Code 00000001
hex
*4
*4. OMRON vendor code
UDINT RO Not
pos-
sible

06 Unit Version
*5
*5. Bits 24 to 31: Integer part of the Unit version.
Bits 16 to 23: Fractional part of the Unit version.
Bits 0 to 15: Reserved
(Example) For Ver.1.0, 0100 hex
UDINT RO Not
pos-
sible

07 Serial Number
*6
*6. A unique serial number is assigned for each product unit.
Bits 0 to 31: Serial number
00000000 to
FFFFFFFF hex
 UDINT RO Not
pos-
sible

1001  Production Info  
00 Number of Entries 2 2  USINT RO Not
pos-
sible

01 Lot Number
*7
00000000 to
FFFFFFFF hex
 UDINT RO Not
pos-
sible

02 Hardware Version
*8
ARRAY
[0..19]
OF BYTE
RO Not
pos-
sible

