9 Troubleshooting

9 - 2

NX-series Digital I/O Unit User’s Manual (W521)

9-1 How to Check for Errors

Use one of the following error checking methods.

• Checking the indicators

• Troubleshooting with the Sysmac Studio

Refer to the user’s manual for the connected Communications Coupler Unit for details on troubleshoot-

ing with the Sysmac Studio.
