6 - 7
6 Digital Input Units
NX-series Digital I/O Unit User’s Manual (W521)
6-3 List of Settings
6
6-3 List of Settings
The followings are the setting descriptions, setting ranges, and default values of the functions that can
be used in the Digital Input Units.
The settings are reflected after the Unit is restarted.
Precautions for Safe Use
The Unit is required to restart after the transfer of Unit operation settings on the Sysmac Studio
is completed. Always sufficiently check the safety at the connected devices before you transfer
the Unit operation settings.
 Four-point Input Units
NX-ID3317/ID3417/IA3117
*1. The descriptions of Input Filter Value Setting are as follows.
NX Units in Free-Run Refreshing or Synchronous I/O Refreshing
Setting name Description
Default
value
Setting
range
Unit Index
Subin-
dex
Refer-
ence
Input Filter Value Setting Set the filter time of input
signal.
*1
*1 *1
 5000
hex
01 hex P. 6-14
Input Filter Mode Setting Set the operating mode
for the filter.
*2
*2 *2
 02 hex
Set
value
Setting description Default value Setting range
0 No Filter 3 0 to 11
1 0.25 ms
2 0.5 ms
31 ms
42 ms
54 ms
68 ms
716 ms
832 ms
964 ms
10 128 ms
11 256 ms
