5 EtherCAT Communications
5 - 8
G5-series Linear Motors/Servo Drives With Built-in EtherCAT Communications
This is the mapping for an application that uses one of the following modes: Cyclic synchronous
position mode (csp), Cyclic synchronous velocity mode (csv), and Cyclic synchronous torque mode
(cst).
Touch probe function is available.
This is the mapping for an application that switches between Cyclic synchronous position mode (csp)
and Cyclic synchronous velocity mode (csv).
Touch probe function and force limit can be used.
This is the mapping for an application that uses one of the following modes: Cyclic synchronous
position mode (csp), Cyclic synchronous velocity mode (csv), and Cyclic synchronous torque mode
(cst).
Touch probe function and force limit can be used.
PDO Mapping 2 (Position Control, Speed Control, Force Control, and
Touch Probe Function)
RxPDO (1702 hex)
Controlword (6040 hex), Target position (607A hex), Target velocity (60FF hex), Target
torque (6071 hex), Modes of operation (6060 hex), Touch probe function (60B8 hex), and
Max profile velocity (607F hex)
TxPDO (1B02 hex)
Error code (603F hex), Statusword (6041 hex), Position actual value (6064 hex), Torque
actual value (6077 hex), Modes of operation display (6061 hex), Touch probe status (60B9
hex), Touch probe pos1 pos value (60BA hex), Touch probe pos2 pos value (60BC hex),
and Digital inputs (60FD hex)
PDO Mapping 3 (Position Control, Speed Control, Touch Probe
Function, and Force Limit)
RxPDO (1703 hex)
Controlword (6040 hex), Target position (607A hex), Target velocity (60FF hex),
Modes of operation (6060 hex), Touch probe function (60B8 hex), Positive torque limit
value (60E0 hex), and Negative torque limit value (60E1 hex)
TxPDO (1B03 hex)
Error code (603F hex), Statusword (6041 hex), Position actual value (6064 hex), Torque
actual value (6077 hex), Following error actual value (60F4 hex), Modes of operation
display (6061 hex),Touch probe status (60B9 hex), Touch probe pos1 pos value
(60BA hex), Touch probe pos2 pos value (60BC hex), and Digital inputs (60FD hex)
PDO Mapping 4 (Position Control, Speed Control, Force Control, Touch
Probe Function, and Force Limit)
RxPDO (1704 hex)
Controlword (6040 hex), Target position (607A hex), Target velocity (60FF hex), Target
torque (6071 hex), Modes of operation (6060 hex), Touch probe function (60B8 hex), Max
profile velocity (607F hex), Positive torque limit value (60E0 hex), and Negative torque limit
value (60E1 hex)
TxPDO (1B04 hex)
Error code (603F hex), Statusword (6041 hex), Position actual value (6064 hex), Torque
actual value (6077 hex), Modes of operation display (6061 hex), Touch probe status (60B9
hex), Touch probe pos1 pos value (60BA hex), Touch probe pos2 pos value (60BC hex),
and Digital inputs (60FD hex)
