Getting To Know Your Machine
Misfed Paper
● Removing Misfed Paper (Paper Transport/Fusing Area) (J01, J30, J31, J33, J45, J48, J95)
REMOVE MISFED PAPER
J48
Left Cover
Paper Tray
Jam Removal
Knob
Left Cover
Corona Cleaner
Toner Bottle (New)
Toner Waste Container
Front Cover
7
Operation Chart
■ Problem Solving
● Removing Misfed Paper (Paper Exit Area) (J46)
● Replacing Toner Bottle/Toner Waste Container
1 2
Slide the Corona Cleaner in and out 3 or
4 times slowly, then return the Corona
Cleaner Handle to original position.
REMOVE MISFED PAPER
J46
(ATTENTION)
● For optimum copy quality
use the recommended
Panasonic Toner. Store
Toner Bottle in a cool
dark place. Do not unseal
the Toner Bottle unless
you are ready to use it.
Shake it well
6
NOTE:
Do not reuse the toner from the
Toner Waste Container.
1 2
1 2
6 7
(Ex.)
(ATTENTION)
● Do not scratch or touch the
surface of the OPC Drum
(Green) with bare hands. The
OPC Drum is sensitive to light.
To prevent optical exposure
problems, do not expose the
OPC Drum to direct sunlight or
bright light.
(Ex.)
To Next Page
