72
Appendix
Type: Desk Top
Platen Type: Fixed
Acceptable Originals: Sheets, Books (max. A3 size)
Copying Method: Laser Electrophotography
Fusing Method: Heat Roller
Imaging Method: Dry-Type Dual Components Imaging
Resolution: Max. 600 dpi
Operation Panel: LCD Display
Copy Size: A3 - A5 via Paper Tray
Void Area: Max. 0.2″ (5 mm)
Warm Up Time: Approx. 30 seconds (20°C)
First Copy Time: Less than 7.0 seconds (A4, from 1st Tray)
Multi-Copy Speed: DP-1520P : 15 cpm (A4 size) ,
DP-1820P/1820E : 18 cpm (A4 size)
Enlargement Ratios: Preset: 115%, 122%, 141%, 173%, 200%
Variable: from 101% to 200% in 1% increments
Reduction Ratios: Preset: 87%, 82%, 71%, 58%, 50%
Variable: from 99% to 50% in 1% increments
Paper Feed: Standard Paper Tray (550 sheets) + Sheet Bypass (50 Sheets)
Optional Paper Trays (550 sheets x 3 )
(3rd and 4th Paper Trays are for DP-1820P/1820E only)
Paper Weight: Paper Tray: 60 - 90 g/m
2
Bypass: 55 - 133 g/m
2
ADU: 64 - 90 g/m
2
(DP-1820E)
Quantity Selector: Max. 999 sheets (Output Tray capacity is 250 sheets/A4 size)
Electrical Consumption: AC 220-240V, 50/60Hz, 6.5A
Power Consumption: Max. 1.3 kW
Dimensions (W)(D)(H): 558 x 557 x 460 mm
Mass (Weight): 40 kg
Operating Environment: Temperature: 10 - 30°C
[Humidity should be 70% or less at 30°C]
Relative Humidity: 30 - 80%
[Temperature should be 27°C or less at 80% RH]
Tray Capacity: A4, A5: 50 sheets (80 g/m
2
)
A3, B4, FLS: 30 sheets (80 g/m
2
)
Original Size: A5/A4/B4/A3/FLS
Paper Weight: 50 - 110 g/m
2
Electrical Requirements: Supplied from the machine
Dimensions (W)(D)(H): DA-AS181: 558 x 501 x 112 mm
DA-AR202: 552 x 520 x 135 mm
Mass (Weight): DA-AS181: 5.0 kg DA-AR202: 9.3 kg
■ DP-1520P/1820P/1820E (For Copier)
Specifications
■ ADF (DA-AS181)/i-ADF (DA-AR202)
