Preparation
Abb. 11 - 02
11 - 2
6
3
7
4
1
2
5
● Place an empty bobbin 1 onto the bobbin shaft 2.
● Thread the machine in accordance with Fig. 11-02.
● Push key 3 to the end of the bobbin shaft 2.
● Regulate the thread tension by turning the milled screw 4.
● Push the foot pedal.
● The bobbin winder stops automatically when the bobbin 1 is full.
● Clamp the thread coming from the spool in the clamp 5 and snap the thread.
● For bobbin winding see section 8.05 Functions of the quick control panel
( switch 3 ).
If the thread winds unevenly:
● loosen nut 6.
● Turn the thread guide 7 accordingly.
● Tighten nut 6.
11.02 Winding the bobbin thread, adjusting the thread tension
