Adjustment
14 - 1
14 Adjustment
All relevant safety regulations are to be adhered to! The machine is to be
separated from the power supply before all adjustment work and to be secured
against accidentally being turned back on!
All adjustments in these adjustment instructions are based on a completely
installed machine. Covers on the machine which have to be removed and
replaced for checks and adjustment work are not mentioned.
The PFAFF 3117 is set up for Singer needles at the factory. When using
needles from other manufacturers the hook settings are to be checked.
14.01 Tools, gauges and other accessories
● Screwdrivers with blade width from 2 to 10 mm
● Screwdrivers with blade width from 7 to 14 mm
● Allan keys from 1.5 to 6 mm
● Offgrub screwdrivers, Part No. 91-029 339-91
● Metal rule, Part No. 08-880 218-00
● Terminal screw, Part No. 08-880 137-00
● Needle rise gauge 2.4 mm, Part No. 61-111 600-09
● Adjustment gauge, Part No. 61-111 635-86
● Knife adjustment gauge, Part No. 61-111 635-85
● Needles, system 438 or 265 or DPX 438
● Sewing thread and test material
● Sewing machine oil: mean viscosity of 22.0 mm
2
/s at 40°C
Density 0.865 g/cm
3
at 15°C
Part No. 280-1-120 144
● Sewing machine oil: mean viscosity of 10.3 mm
2
/s at 40°C
Density 0.847 g/cm
3
at 15°C
Part No. 280-1-120 105
