Specification Desc./Quantity
Consumption (CUNA) ~2.7 litres per 100 km.
Km range Around 370 Km.
GEAR RATIO
Specification Desc./Quantity
Gear ratio First 1/54.17
Gear ratio Second 1/29.75
Gear ratio Third 1/19.28
Gear ratio Fourth 1/13.35
Gear ratio Reverse 1/76.47
STEERING
Specification Desc./Quantity
Steering Steering tube pivoted on the arm with front wheel-holder oscil-
lating clamp.
SUSPENSION
Specification Desc./Quantity
Front - rear suspension Made using integrated helicoidal springs and hydraulic shock
absorber.
TYRES
Specification Desc./Quantity
Wheel rim 2.10"
Front tyre pressure 1.5 bar.
Rear tyre pressure 2.5 bar.
TYRES - APE 50 - APE 50 EUROPA - APE 50 EUROPE EURO 2 - APE 50 MIX
Specification
Desc./Quantity
Wheel rim 10-2.50"
Tyre 100/90x10"
Front tyre pressure 2 bar.
Rear tyres - inflation pressure 3 bar.
Tightening torques
ENGINE - DIFFERENTIAL UNIT
Name
Torque in Nm
Crankcase halves coupling nuts 13 to 15 Nm
Coil support fixing screw 3 to 5 Nm
Spark plug 14 to 18 Nm
Engine gear locking nut 50 to 55 Nm
Clutch assembly locking nut 40 ÷ 45 Nm
Fan flywheel locking nut 45 to 50 Nm
Filler joint fixing nuts 5 to 7 Nm
Nuts fixing the exhaust pipe to the cylinder 5 to 7 Nm
Clutch cover fixing bolts 6 to 8 Nm
Big end fixing bolts 13 to 18 Nm
Nuts fixing the cylinder to the crankcase 13 to 15 Nm
Nuts fixing the differential unit to the engine 32 to 35 Nm
Differential crankcase halves coupling nuts 8 to 10 Nm
Engine - chassis anchoring plate fixing nuts 20 to 24 Nm
Differential oil drain plug 20 ÷ 25 Nm
Gear control guide bushing 60 to 65 Nm
Nuts fixing the silencer to the engine support 23 to 25 Nm
Nuts fixing the elastic connection to the engine support 25 to 30 Nm
Engine front fixing bolt 25 to 30 Nm
MSS APE 50 Characteristics
CH - 13
