Wiper switch
In working position, contact between the White
and White Black cables.
POSITIONS OF THE WINDSCREEN WIPER
SWITCH - APE 50 MIX - APE 50 EUROPE
0 = Windscreen wiper turned off
1 = Windscreen wiper turned on
2 = Windscreen washer enabling
Pulsante avviamento
In working position, contact between the White
and Green Black cables.
MSS APE 50 Electrical system
ES - 63
