Stator
For refit operations, operate in the opposite direc-
tion to the removal, bearing in mind the following:
position the stator as shown, correctly position the
key, and lock the flywheel nut to the prescribed
torque.
Locking torques (N*m)
Fan flywheel locking nut 45 to 50 Nm
Crankcase splitting
Fitting:
Clean the mating surfaces thoroughly.
Position a new gasket on the flywheel side crank-
case halves.
Join the two crankcase halves.
Insert the flywheel side seal ring.
MSS APE 50 Engine
EN - 73
