PIAGGIO MSS APE 50 User Manual

km x 1,000 (months) 1 (4) 5 (12) 10
(24)
15
(36)
20 25 30 35 40 45 50
Gearbox oil - Replacement/Inspection (I) (R) (I) (R) (I) (R) (I) (R) (I) (R)
Differential oil - Replacement/Inspection (I) (R) (I) (R) (I) (R) (I) (R) (I) (R)
Battery fluid level - Inspection (I) (I) (I) (I) (I) (I) (I) (I) (I) (I) (I)
Headlights - check/adjust (I) (I) (I) (I) (I) (I)
Suspension - Inspection (I) (I) (I) (I) (I)
Flexible transmissions - Lubrication (I) (I) (I) (I) (I)
Rear brake disc piping - Replacement (R)
Vehicle and brake test (I) (I) (I) (I) (I) (I) (I) (I) (I) (I) (I)
Air filter and SAS box (sponge) cleaning (R) (R) (R) (R) (R)
Suggested products chart
RECOMMENDED PRODUCTS TABLE
Product Description Specifications
AGIP CITY TEC 2T Oil mixer for 2-stroke engines JASO FC, ISO-L-EGD Specifications
AGIP CITY HI TEC 4T Oil for lubricating the flexible transmission
lines (brakes, throttle grip, odometer,
etc.).
Specifications: SAE 5W-40, API SL,
ACEA A3, JASO MA
AGIP GEAR Differential Oil Specifications: SAE 80W-90; API GL-4
AGIP GEAR Gearbox oil SAE 80W-90; API GL-4
AGIP GREASE PV 2 Grease for brake control levers Specifications: NLGI 2 ; ISO-LXBIB2
AGIP GREASE MU3 Grease for odometer transmission gear
case
Specifications: NLGI 3; ISO-L-XBCHA3,
DIN K3K-20
AGIP BRAKE 4 Brake fluid FMVSS DOT 4
Carburettor
The carburettor is completely decomposed, check all calibrated parts (main jets, idle jets, emulsifiers
tubes, etc.). The value of these calibrated parts must correspond to the adjustment data prescribed for
the type of carburettor. For a thorough cleaning of all components of the carburettor, use a bath of
suitable solvent and blow with compressed air. To clean the calibrated jets, avoid using metallic spikes
or wires.
All gaskets, seal rings and springs of the carburettor, should be replaced with each revision.
WARNING
THE CARBURETTOR IS VERY EXPLOSIVE; BE VERY CAREFUL NOT TO SPILL FUEL DURING
THE REMOVAL OF THE CARBURETTOR
WARNING
USE EXTREME CAUTION WHEN WORKING ON COMPONENTS CONTAINING PETROL.
WARNING
PETROL IS HIGHLY EXPLOSIVE
ALWAYS REPLACE THE GASKETS TO AVOID PETROL LEAKS
SPECIFICATIONS
Specification
Desc./Quantity
Dell'Orto type SHBC 18/16 A.
Diffuser mm. 16.
Max. jet 60/100.
Minimum jet 42/100 long.
Minimum fixed air 110/100.
Maximum fixed air 150/100.
Starter jet 50/100.
MSS APE 50 Maintenance
MA - 31
