MAINTENANCE OPERATIONS
In the event of prolonged vehicle inactivity, adhere to the following standards:
1) Clean the vehicle.
2) Remove the fuel from the vehicle.
3) Remove the air filter and with the engine is running at low rpm and input 30 cc. of specific oil through the diffuser of the
carburettor.
4) Spread antirust grease on the unpainted metallic parts.
5) Lift the wheels off the ground.
A) Operation to be carried out when the engine is warm. Amount of new oil: about 600 gr. for the engine unit (until touching the
load hole) and about 300 gr. for the differential unit (maximum level on the check rod).
B) For the oil level in the tank and to replace, use specific oil.
Unit Operations After the
first 1000
Km
Every
4000 Km
Every
8000 Km
In the
event of a
review
Notes
MOTOR
Carburettor locking • See locking torque ta-
ble:
Piston - big end - cylin-
der lights descaling
• See locking torque ta-
ble:
Cleaning and descaling
of the still usable engine
parts
• See locking torque ta-
ble:
TRANSMISSION AND
DIFFERENTIAL
Oil replacement •(A) •(A) •
Check and restore oil
level
•
air filter
Cleaning • Clean with pure petrol
and dry with com-
pressed air
SPARK PLUG
Electrode gap and des-
caling check
• • Bosch W54C; Lodge
2HN; Champion L82C;
NGK B6HS;
Replacement • Bosch W54C; Lodge
2HN; Champion L82C;
NGK B6HS;
BEARINGS
Grease •
ARTICULATIONS AND
CONTROL LEVERS
(ENGINE SIDE)
Grease • •
HYDRAULIC BRAKE
Check and restore oil
level
•(B)
FLEXIBLE TRANSMIS-
SIONS
Adjust •
Lubricate • •
MAIN NUTS AND
BOLTS OF THE VEHI-
CLE
Locking check • • See locking torque ta-
ble:
SCHEDULED MAINTENANCE - APE 50 EUROPA
KEY: (*)= Every 2 years.
(I) = Check and clean, adjust, lubricate or replace if necessary.
(R)=Replace
In the event of prolonged vehicle inactivity, adhere to the following standards:
1) Clean the vehicle.
2) Remove the fuel from the vehicle.
Maintenance MSS APE 50
MA - 28
