4.If this is not so, adjust the headlight by means of
the two screws (1) to correct any beam alterations.
Cables adjustment
SPLITTER_ADJUSTMENT CONTROL CABLE
Splitter control cable «1»: adjust so that clearance
is felt on the throttle grip.
Mixer cable «2»: see section "Mixer timing".
Throttle grip cable «3»: adjust so that the sheath
does not have clearance.
TRANSMISSIONS ADJUSTMENTS
Adjust the control cables: Cable mix: see "mixer timing" specification section.
Gas cable: adjust so that the sheath does not have clearance.
Splitter control cable: adjust so that clearance is felt on the throttle grip. All transmissions must be
adjusted so that the sheaves have no clearances.
MSS APE 50 Maintenance
MA - 37
