ELECTRICAL SYSTEM DEVICES - APE 50 EUROPA
1. FRONT HEADLIGHTS, 12V-3W, 12V- 15W AND 12V-10W BULBS
2. HORN
3. REAR HEADLIGHTS, 12V-4W, 12V-10W AND 12V-10W BULBS
4. WINDSCREEN WIPER
5. INSTRUMENT PANEL, 12V- 1.2W BULBS
6. WINDSCREEN WIPER SWITCH
7. STARTER BUTTON
8. LIGHT SWITCH
9. TURN INDICATOR SWITCH
10. HORN BUTTON
11. IGNITION SWITCH
12. STOP BUTTON
13. TURN INDICATOR CONTROL DEVICE
14. LOW FUEL WARNING LIGHT CONTROL
15. START-UP MOTOR
16. 8A FUSE
17. START-UP REMOTE CONTROL SWITCH
18. VOLTAGE REGULATOR
19. 12V-9Ah BATTERY
20. ELECTRONIC CONTROL UNIT
Electrical system MSS APE 50
ES - 52
