REAR WHEEL BRAKE DRUM LOCKING
When refitting the drum brake on the wheel axle,
do not reuse the previously removed chamfered
nut, but replace it with a new one; the locking must
be carried out, chamfering carefully with a (steel)
punch, the collar in the existing groove on the
wheel-holder shaft, then fit the cover after filling it
with specific grease.
Recommended products
AGIP GREASE PV 2 Grease for brake control
levers
Specifications: NLGI 2 ; ISO-LXBIB2
Locking torques (N*m)
Rear wheel brake drum locking 80 to 100 Nm
KEY:
*= chamfer.
Parking brake control and brake shoes
Brake cylinder and shoe disc
Suspensions MSS APE 50
SS - 98
