Page #97 background imageLoading...
Page #97 background image
Roller cage and split ring on brake drum
Specific tooling
033970Y Punches for Roller Casings
Ball bearing and split ring on brake drum
Heat the bearing housing area with the appropriate
tools and fit the ball bearing and the circlip.
CAUTION
BEFORE REFITTING THE DRUM, FILL THE INTERNAL
CHAMBER WITH THE SPECIFIC GREASE.
Specific tooling
020151Y Heat gun
Drum and rear wheel
MSS APE 50 Suspensions
SS - 97
