WHEN INTERVENING ON THE ELECTRICAL SYSTEM, MAKE ESPECIALLY SURE THAT THE
WIRES LEADING TO THE ELECTRONIC CONTROL UNIT ARE CORRECTLY CONNECTED AND
RESPECT THE COLOUR CODING GIVEN ON THE CONTROL UNIT.
ELECTRICAL SYSTEM DEVICES - APE 50 mix (CROSS VERSION)
1. FRONT HEADLIGHTS AND TURN INDICATORS, 12V-3W, 12V- 15W AND 12V-10W BULBS
2. HORN
3. REAR LIGHTS, 12V-4W, 12V-10W AND 12V-10W BULBS
4. WINDSCREEN WIPER
5. INSTRUMENT PANEL, 12V- 1.2W BULBS
6. WINDSCREEN WIPER SWITCH
7. STARTER BUTTON
8. LIGHT SWITCH
9. TURN INDICATOR SWITCH
10. HORN BUTTON
11. IGNITION SWITCH
12. STOP BUTTON ON THE REAR BRAKE
13. CIGARETTE LIGHTER
14. LOW FUEL WARNING LIGHT CONTROL
15. OIL RESERVE WARNING LIGHT CONTROL
16. START-UP MOTOR
17. CIGARETTE LIGHTER LIGHTING, 12V-1.2W BULB
18. STOP BUTTON ON THE FRONT BRAKE
19. STARTER RELAY
20. Voltage regulator
21. 12V-9AH BATTERY
22.ELECTRONIC CONTROL UNIT
23.SPARK PLUG
24. MAGNETO FLYWHEEL
25. INTERNAL LIGHT FITTING, 12V-5W BULB
26. 20A (GENERAL) FUSE
27.(CIGARETTE LIGHTER AND LIGHT FITTING) 10A FUSE
28. 7.5A (SERVICE) FUSE
29. 4A FUSE (DAYLIGHT RUNNING LIGHT)
30. 4A FUSE (LOW-BEAM LIGHTS)
31. DIGITAL CLOCK LIGHTING, 12V-1.2W BULBS
32. DIGITAL CLOCK
33. TURN INDICATOR CONTROL DEVICE
MSS APE 50 Electrical system
ES - 57
