13.1.3 Example C: offices/shops
Figure 4. Partitions - Example D
This is an example for office or shop floor. Each office/shop is assigned to a partition. The whole
floor can be controlled by one keypad, with each occupant having a separate user code, remote
control, key switch and RFID tag.
The keypad can display the status of all partitions, though the users will only be able to control
their partition.
13.1.4 Armed partitions display
Armed partitions are displayed with “X”, above the partition number.
