Pima FORCE Series Installation Guide

6: Outputs
PIMA Electronic Systems 23
6 Outputs
The Outputs menu includes the following sub-menus:
1)  Onboard: see below.
2)  Zone Expanders: see section 6.2.
3)  Outputs Expander: see section 6.3.
4) Wireless Sirens: see section 6.4.
6.1 Onboard
System Configuration  Outputs  Onboard
The Onboard menu includes the following sub-menus (outputs):
1)  External Siren
2)  Internal Siren
3)  Relay
4)  On/Off
5)  Alrm
All the outputs has the following parameters:
Parameter
Description
 Output
Type
Set the output types (event) that will trigger the selected physical output. The
triggering timer is set in the Timers and Counters menu. See the complete list of
the programmable output types in Appendix C., on page 41.
The next types are followers only.
Programmable
output type
is triggered when...
Zone open
a zone is opened (triggered)
Full arm
The alarm system is armed (in any mode)
Technician on-site
Technician code is entered
Walk test
entering walk test mode
The default programmable output types do not need to be
changed in most installations.
 Positive
Polarity
Set the output’s polarity:
ON/OFF, Alrm (Open Collector)
 Checked: the output is normally switched to ground and disconnected
when activated.
 Cleared: the output is normally disconnected and supplies ground when
activated.
Relay
 Checked: the C and NC terminals are normally shorted. When activated,
the C and NO terminals are shorted.
 Cleared: the C and NO terminals are normally shorted; C and NC
terminals are shorted when activated.
