FORCE Series Insta
llation Guide
44
PIMA Electronic
Systems
Appendix F.
Zone
and System Statu
s
1.
Zone status
Letter
Indication
A
Zone alar
m
B
Zone bypa
ss
C
Chime zon
e
F
Fault (tamper/di
sconnectio
n/short)
L
Low battery
(wireless peripheral
)
M
Anti-mask
alarm (wireless peri
pheral)
O
Armed partit
ion
T
Zone te
st
V
Supervisio
n loss (wireless peri
pheral)
2.
System status (main scree
n)
Letter
Indication
G
Cellular
data commun
ication
N
Network in use (in
cluding with
PIMA cloud)
P
Phone lin
e in use
R
Relay (device) activ
ation
S
Siren acti
vation
43
45
Table of Contents
Default Chapter
2
Table of Contents
2
1 Introduction
5
Main Features
5
System Comparison Table
6
Technical Specifications
7
Ordering Information
7
Peripherals
7
2 The Control Panel
9
Location Guidelines
9
Installation
9
The Control Panel's Circuit Board
10
Figure 1. the Control Panel's Rack
10
Figure 2. the Rack's Lid
10
Figure 3. the Control Panel's Circuit Board Diagram
10
The Bus
11
Zone Wiring
11
Figure 4. no EOL
11
Figure 5. One EOL
11
Figure 6. Two Eols
11
Zone Doubling
12
Tamper Switches
12
Wired Sirens
12
Alarm and On/Off Outputs
12
Figure 7. Sirens Connection Diagram
12
Relay
13
Wired Keypads
13
Keypad ID Number
13
Phone Line and Set
13
Figure 8. Line and Set Connections
13
3 System Programming
14
Menus and Codes
14
Code Setting Guidelines
14
Activation Codes
14
Changing the Default Master and Technician Codes
14
The Technician Menu
15
System Configuration
15
Tests & Diagnostics
15
4 Peripherals
16
Zone Expanders
16
Tampers and Eols
16
Keypad Settings
17
Wireless Peripherals
17
5 Zones
20
Zone Settings
20
Zone Types Settings
21
Attributes
21
Copy Zones
22
Single to Multiple
22
Multiple to Multiple
22
Partitions Names
22
6 Outputs
23
Onboard
23
The Ext./Int. Siren Outputs
24
Zone Expanders
24
Outputs Expander
24
Wireless Sirens
24
7 CMS & Communications
25
Monitoring Stations
25
Cms 1-2
25
Radio
27
Custom Zones Reports
28
PIMA Cloud
28
General Settings
29
Telephone Settings
29
Network Settings
29
Cellular Settings
30
8 Faults
31
AC Fault
31
Low Battery, Phone Line, Network, Cellular Module
31
Invalid Code
31
CMS Comm., Tamper Open, Invalid Code, Other Faults
31
9 Timers and Counters
32
Programmable Output Types
33
10 General Settings
34
Arming Prevention
35
11 Reset to Defaults
36
Resetting to Factory Defaults
36
12 Tests & Diagnostics
37
Event Memory
37
Zone Test
37
Figure 9. Event Memory Log
37
Output Test
38
Power Diagnostics
38
Communication Tests
38
Communication Monitor
38
Wireless Peripherals
38
Appendix A. Implementing Partitions
39
Appendix B. Remote Up/Download
40
Appendix C. Programmable Output Types
41
Appendix D. Technician and CMS Codes
42
Appendix E. Text and Characters
43
Appendix F. Zone and System Status
44
Appendix G. CMS Event Reporting
45
Appendix H. Glossary
46
