Force Security System - Installation Guide
16
Figure 15. ZEX516 connection diagram
2.9.8 Remote 8-relay outputs expansion card, OEX508
The OEX508 has 8 relay outputs for connecting various peripherals and devices.
Main features
 8 Normally Open/Normally Closed/COM relay outputs
 Multiple voltage and COM terminals
 Interfaces with the BUS
 External tamper switch input
 Tamper bypass jumper
 Technician keypad fast connector
 PS-2 power supply socket
 ID number DIP switch
 Card location buzzer
 Supplied mounted in a standard plastic 19 X 13cm box
 Size: 8.2 X 15cm
 Technical specs: 10-15V, 30mA in idle state, Fuse: 0.9A
POWER SUPPLY
ID
1
+
2 3 4 5 6 7 8
1(-) 2(+) 3 4
ForceBus
TAMPER
RELAY 1
NC Com NO
BOOT
Int Tamper
Disconnect
RUN
BUS
(-)
1 2 3 4
1
2
3
4
9
+
10 11 12 13 14 15 16
+
+
+
+
NC
NO
COM
RELAY 2
+12VDC
To Control Panel
and other
Peripherals (BUS)
External
Tamper Input
Relay #1
Output
Zone Inputs and Aux. Voltage
RUN LED
BUS LED
Tamper
Jumper
Box Mounting
Hole
To PS-2
Power Supply
Buzzer
Technician
Keypad
Connector
Tamper Switch
Expander’s ID
Dip Switch
NC
Com
NO
Relay #2
Output
(-)
NO
Com
NC
