Pioneer DJM-900NXS Service Manual

164
DJM-900NXS
1
2 3 4
A
B
C
D
E
F
1
2 3 4
10.34 USBI and HPJK ASSYS
H
CN 3801
KM200NA5L
GN DD
1
GN DD
2
D-USB 3
D+USB 4
V+5V BUS
5
C3802
NM
C3801
DCH1201-A
10u 10V
D3801
NM
FGND
GN DD
FGND
FGNDFGND
DKN1237-A
JA3801
V+5_SUB
1
D-USB
2
D+USB
3
GN DD
4
GN DD
RT1
GN DD
RT2
CKF1089-A
KN 3801
1
L3801
ATH7015-A
12
34
VA3801
NM
VA3802
NM
V+5V BUS
C3803
100p/50
CH
GN DD
C3804
2p/50
C3805
2p/50
C3806
100p/50
CH
USB2.0 High speed
B Type
NM
NOTES
CH
CKSRYB****
CKSSYB****
RS1/16S****J
RS1/10S****J
is STBY
CCSRCH****
CCSSCH****
CCSQCH****
STBY
STBY
STBY
G
11/21
CN1802
H
USBI ASSY (DWX3192)
: USB IN/OUT Signal
(USB IN/OUT)
(USB IN/OUT)
(USB IN/OUT)
5-1
5-2
: Waveform measuring point

Pioneer DJM-900NXS Specifications

General

Sample rate	96 kHz
Frequency range	20 - 20000 Hz
Channels quantity	4 channels
Digital sound processing	24 bit
Number of EQ bands per channel	3
Line Signal-to-Noise Ratio (SNR)	107 dB
Total Harmonic Distortion (THD)	0.004 %
Microphone in	Yes
Line inputs (RCA)	6
Phono inputs (RCA)	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Digital audio coaxial out	1
Power consumption (typical)	42 W
