Pioneer DJM-900NXS Service Manual

9
DJM-900NXS
5
6 7 8
5
6 7 8
A
B
C
D
E
F
2. SPECIFICATIONS
2.1 SPECIFICATIONS
General
Power requirements........................AC 220 V to 240 V, 50 Hz/ 60 Hz
(SYXJ8, XJCN5)
AC 120 V, 60 Hz (UXJCB)
AC 110 V to 120 V or 220 V to 240 V, 50 Hz/ 60 Hz (LXJ)
AC 220 V, 60 Hz (KXJ5)
Power consumption.....................41 W (SYXJ8, LXJ, KXJ5, XJCN5)
42 W (UXJJCB)
Power consumption (standby)...................................................0.4 W
Main unit weight.........................................................7.1 kg (15.7 lb)
Max. dimensions............331 mm (W) × 107.9 mm (H) × 409 mm (D)
(13 in. (W) × 4.2 in. (H) × 16.1 in. (D))
Tolerable operating temperature...............................+5 °C to +35 °C
(+41 °F to +95 °F)
Tolerable operating humidity..............5 % to 85 % (no condensation)
Audio Section
Sampling rate ........................................................................ 96 kHz
A/ D, D/ A converter............................................................... .24 bits
Frequency characteristic
CD/ LINE.............................................................20 Hz to 20 kHz
S/ N ratio (rated output)
PHONO...............................................................................88 dB
CD/ LINE...........................................................................105 dB
MIC1, MIC2.........................................................................84 dB
Total harmonic distortion (CD/ LINE — MASTER1)............ 0.005 %
Standard input level / Input impedance
PHONO...............................................................–52 dBu/ 47 kΩ
CD/ LINE.............................................................–12 dBu/ 47 kΩ
MIC1......................................................................–52 dBu/ 8 kΩ
MIC2....................................................................–52 dBu/ 12 kΩ
RETURN..............................................................–12 dBu/ 47 kΩ
Standard output level / Load impedance / Output impedance
MASTER1.......................................+8 dBu/ 10 kΩ/ 5 Ω or lower
MASTER2......................................+2 dBu/ 10 kΩ/ 22 Ω or lower
REC OUT.......................................–8 dBu/ 10 kΩ/ 22 Ω or lower
BOOTH..........................................+8 dBu/ 10 kΩ/ 1 kΩ or lower
SEND...........................................–12 dBu/ 10 kΩ/ 1 kΩ or lower
PHONES........................................+8.5 dBu/ 32 Ω/ 1 Ω or lower
Rated output level / Load impedance
MASTER1............................................................+26 dBu/ 10 kΩ
MASTER2............................................................+22 dBu/ 10 kΩ
Crosstalk (LINE).......................................................................82 dB
Channel equalizer char
acteristic
HI..........................................................–26 dB to +6 dB (13 kHz)
MID.........................................................–26 dB to +6 dB (1 kHz)
LOW........................................................–26 dB to +6 dB (70 Hz)
Microphone equalizer characteristic
HI........................................................–12 dB to +12 dB (10 kHz)
LOW....................................................–12 dB to +12 dB (100 Hz)
Input / Output terminals
PHONO input terminal
RCA pin jack........................................................................2 sets
CD/ LINE input terminal
RCA pin jacks......................................................................4 sets
LINE input terminal
RCA pin jack........................................................................2 sets
MIC1 input terminal
XLR connector/ phone jack (Ø 6.3 mm)................................1 set
MIC2 input terminal
Phone jack (Ø 6.3 mm).........................................................1 set
RETURN Input terminals
Phone jack (Ø 6.3 mm).........................................................1 set
DIGITAL IN coaxial input terminal
RCA pin jacks......................................................................4 sets
MASTER output terminal
XLR connector......................................................................1 set
RCA pin jack........................................................................1 sets
BOOTH output terminal
Phone jack (Ø 6.3 mm).........................................................1 set
REC OUT output terminal
RCA pin jack........................................................................1 sets
SEND output terminal
Phone jack (Ø 6.3 mm).........................................................1 set
DIGITAL MASTER OUT coaxial output terminal
RCA pin jack........................................................................1 sets
MIDI OUT terminal
5P DIN...................................................................................1 set
PHONES output terminal
Stereo phone jack (Ø 6.3 mm)..............................................1 set
USB terminal
B type....................................................................................1 set
LINK terminal
LAN terminal (100Base-TX)..................................................1 set
• The specifications and design of this product are subject to
change without notice.
• CD-ROM
(DXX2619)
• USB cable
(DDE1128)
• Power cord
(SYXJ8: ADG7062, UXJCB: DDG1108, LXJ: ADG7062,
KXJ5: XDG3066, /XJCN5: ADG7105)
• Operating instructions
(SYXJ8: DRB1533, UXJCB: DRB1542, LXJ: DRB1543,
KXJ5: DRB1545, /XJCN5: DRB1544)
Accessories

Pioneer DJM-900NXS Specifications

General

Sample rate	96 kHz
Frequency range	20 - 20000 Hz
Channels quantity	4 channels
Digital sound processing	24 bit
Number of EQ bands per channel	3
Line Signal-to-Noise Ratio (SNR)	107 dB
Total Harmonic Distortion (THD)	0.004 %
Microphone in	Yes
Line inputs (RCA)	6
Phono inputs (RCA)	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Digital audio coaxial out	1
Power consumption (typical)	42 W
