Pioneer DJM-900NXS Service Manual

194
DJM-900NXS
1
2 3 4
A
B
C
D
E
F
1
2 3 4
11.2 MIC1 and TRM1 to TRM4 ASSYS
B C D E F
B
MIC1 ASSY
C
TRM1 ASSY
D
TRM2 ASSY
E
TRM3 ASSY
F
TRM4 ASSY
SIDE A SIDE A
61
DWX3207- MIC1
JA9001
C7
[[ G ]]
CN9001
C9001 C9002
1
5
15
1
2
11
DWX3203-
TRM1
10
C8201
CN8201
VR8201
[[ G ]]
A30C5/C7
LF
10
15
1
5
1
2
11
DWX3204-
TRM2
10
C8401
CN8401
VR8401
A30C5/C7
[[ G ]]
LF
10
15
1
5
1
2
11
DWX3205-
TRM3
10
C8601
VR8601
CN8601
A30C5/C7
[[ G ]]
LF
1
5
10
15
1
2
11
DWX3206-
TRM4
10
C8801
VR8801
CN8801
A30C5/C7
[[ G ]]
LF
1
5
10
15
(DNP2625-B)
(DNP2627-A)
A
CN6201
CN9001
A
CN4201
CN8201
(DNP2625-B)
A
CN4601
CN8401
(DNP2625-B)
A
CN5001
CN8601
(DNP2625-B)
A
CN5401
CN8801
CN9001
1. MIC1_HOT
2. MIC1_HOT
3. GNDA
4. GNDA
5. MIC1_COLD
6. MIC1_COLD

Pioneer DJM-900NXS Specifications

General

Sample rate	96 kHz
Frequency range	20 - 20000 Hz
Channels quantity	4 channels
Digital sound processing	24 bit
Number of EQ bands per channel	3
Line Signal-to-Noise Ratio (SNR)	107 dB
Total Harmonic Distortion (THD)	0.004 %
Microphone in	Yes
Line inputs (RCA)	6
Phono inputs (RCA)	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Digital audio coaxial out	1
Power consumption (typical)	42 W
