Polaris RZR XP 1000 2017 Service Manual

5
9928492 R04 - 2017-2018 RZR XP 1000 / XP4 1000 Service Manual
© Copyright Polaris Industries Inc.
5.3
GENERAL INFORMATION
SPECIAL TOOLS AND SUPPLIES
PART NUMBER TOOL DESCRIPTION
2872085 Drive Clutch Puller
2871056 Driven Clutch Puller
9314177
Clutch Holding Wrench
2871358-A
Clutch Holding Fixture
PU- 50578
Spider Jam Nut Socket
2870341
Clutch Spider Removal and
Installation Tool
2870910 Roller Pin Tool
2871226
Drive Clutch Bushing Replacement
Tool Kit
2870386 Piston Pin Puller
PU-50518
Driven Clutch Compression Tool
2878925
Shock Spanner / Clutch Spreader
Bosch Automotive Service Solutions: 1-800-345-2233
or http://polaris.service-solutions.com/
SPECIAL SUPPLIES
PART
NUMBER
Loctite® 620™ 648™ and 7088™
Primer
N/A
RTV Silicone Sealer
8560054
RZR XP 1000 CLUTCH CHART
MODEL
ALTITUDE
METERS (FEET)
SHIFT
WEIGHT
DRIVE
SPRING
DRIVEN
SPRING
XP 1000
0-1800
(0-6000)
29-75,PM
(5633720)
Black / Red
(7044263)
Black
(7044708)
1800-3700
(6000-12000)
29-68,PM
(5139618 )
RZR XP 4 1000 CLUTCH CHART
MODEL
ALTITUDE
METERS (FEET)
SHIFT
WEIGHT
DRIVE
SPRING
DRIVEN
SPRING
XP4 1000
0-1800
(0-6000)
29-75,PM
(5633720)
Black / White
lettering
(7044504)
Black
(7044708)
1800-3700
(6000-12000)
29-68,PM
(5139618 )
RZR XP 1000 HIGH LIFTER CLUTCH CHART
MODEL
ALTITUDE
METERS (FEET)
SHIFT
WEIGHT
DRIVE
SPRING
DRIVEN
SPRING
XP 1000
High Lifter
0-1800
(0-6000)
29-70,PM
(5633321)
Black / White
lettering
(7044465)
Black
(7044709)
1800-3700
(6000-12000)
29-66,PM
(5633496 )
RZR XP 4 1000 HIGH LIFTER CLUTCH
CHART
MODEL
ALTITUDE
METERS (FEET)
SHIFT
WEIGHT
DRIVE
SPRING
DRIVEN
SPRING
XP4 1000
High Lifter
0-1800
(0-6000)
29-70,PM
(5633321)
Black / White
lettering
(7044465)
Black
(7044709)
1800-3700
(6000-12000)
29-66,PM
(5633496 )
RZR XP 1000 LE GOLD METALLIC CLUTCH
CHART
MODEL
ALTITUDE
METERS (FEET)
SHIFT
WEIGHT
DRIVE
SPRING
DRIVEN
SPRING
2017 LE
Matte
Gold
Metallic
0-1800
(0-6000)
29-75,PM
(5633720)
Black / Red
(7044263)
Black
(7044708)
1800-3700
(6000-12000)
29-68,PM
(5139618 )
PVT SYSTEM
