Polaris RZR XP 1000 2017 Service Manual

9
9928492 R04 - 2017-2018 RZR XP 1000 / XP4 1000 Service Manual
© Copyright Polaris Industries Inc.
9.3
GENERAL INFORMATION
SPECIAL TOOLS
PART NUMBER TOOL DESCRIPTION
2870975
Mity Vac™ Pressure Test Tool
Bosch Automotive Service Solutions:
1-800-345-2233 or http://polaris.service-solutions.com/
GENERAL SPECIFICATIONS
FRONT BRAKE SYSTEM
Item
Standard Service Limit
Front Brake Pad Thickness
.297 ± .007" (7.54 ± .178 mm) .180" (4.6 mm)
Front Brake Disc Thickness
.188" (4.78 mm) .170" (4.32 mm)
Front Brake Disc Runout
- .010" (.254 mm)
REAR BRAKE SYSTEM
Item
Standard Service Limit
Rear Brake Pad Thickness
.298 ± .007" (7.57 ± .178 mm) .180" (4.6 mm)
Rear Brake Disc Thickness
.188" (4.78 mm) .170" (4.32 mm)
Rear Brake Disc Runout
-
.010" (.254 mm)
PARK BRAKE SYSTEM (INT’L MODEL)
Item
Standard Service Limit
Park Brake Pad Thickness
Inboard - .300″ (7.62 mm) .240″ (6.10 mm)
Outboard - .250″ (6.35 mm) .190" (4.83 mm)
Park Brake Disc Thickness
.175 - .185″ (4.44 - 4.70 mm) .150" (3.81 mm)
BRAKE SYSTEM SERVICE NOTES
Disc brake systems are light weight, low maintenance, and perform well in the conditions this vehicle will routinely
encounter. There are a few things to remember when replacing disc brake pads or performing brake system service to
ensure proper system function and maximum pad service life.
• DO NOT over-fill the master cylinder fluid reservoir.
• Make sure the brake pedal returns freely and completely.
• Adjust stop pin on brake caliper(s) after pad service.
• Check and adjust master cylinder reservoir fluid level after pad service.
• Make sure atmospheric vent on reservoir is unobstructed.
• Test for brake drag after any brake system service and investigate cause if brake drag is evident.
• Make sure caliper moves freely on guide pins (where applicable).
• Inspect caliper piston seals for foreign material that could prevent caliper pistons from returning freely.
• Perform a brake burnishing procedure after installing new pads to maximize service life.
• DO NOT lubricate or clean the brake components with aerosol or petroleum products. Use only approved brake
cleaning products.
BRAKE SYSTEM
