3
3.51
9924864 - 2012-2014 SPORTSMAN 800 / 6X6
© Copyright 2013 Polaris Sales Inc.
40. Remove balance shaft and crankshaft.
41. Remove and inspect crankshaft main journal
bearings for abnormal wear. It is recommended to
replace the bearings anytime the engine is
disassembled.
NOTE: Plain bearing clearances may be checked
using a commercially available plasti-gauge
material.
Camshaft Inspection
1. Thoroughly clean the cam shaft.
2. Visually inspect each cam lobe for wear, chafing or
damage.
3. Measure height of each cam lobe using a
micrometer. Compare to specification.
Cam Lobe Height
(Intake & Exhaust):
Std.: 1.3334" (33.8674 mm)
ENGINE
