7.55

9924864 - 2012-2014 SPORTSMAN 800 / 6X6

REAR DRIVE (CV) SHAFT

Inspection

Check the front and rear driveshaft CV boots for any

tears or leaking grease. If the driveshaft boot loses all

grease, CV joint failure will occur.

Removal

1. Remove rear hub. Refer to “REAR HUB REMOVAL”

in this chapter.

2. Remove upper carrier bolt. Tip hub outward and

remove shaft from carrier.

3. Pull sharply outward to remove shaft from

transmission. Install a new compression ring and

apply an anti-sieze compound to the splines upon

assembly.

FINAL DRIVE
