Polaris Sportsman 800 EFI Big Boss 6x6 2013 User Manual

1.13
9924864 - 2012-2014 SPORTSMAN 800 / 6X6
© Copyright 2013 Polaris Sales Inc.
Standard Bolt Torque Specification
BOLT SIZE
GRADE 2
FT. LBS. (NM)
GRADE 5
FT. LBS. (NM)
GRADE 8
FT. LBS. (NM)
1/4-20
5 (7) 8 (11) 12 (16)
1/4-28
6 (8) 10 (14) 14 (19)
5/16-18
11 (15) 17 (23) 25 (35)
5/16-24
12 (16) 19 (26) 29 (40)
3/8-16
20 (27) 30 (40) 45 (62)
3/8-24
23 (32) 35 (48) 50 (69)
7/16-14
30 (40) 50 (69) 70 (97)
7/16-20
35 (48) 55 (76) 80 (110)
1/2-13
50 (69) 75 (104) 110 (152)
1/2-20
55 (76) 90 (124) 120 (166)
Metric Bolt Torque Specification
BOLT
SIZE
GRADE
4.6 4.8 8.8 / 8.9 10.9 12.9
FT.— LBS. (NM) DRY THREADS
M3
.3 (.5) .5 (.7) 1 (1.3) 1.5 (2) 1.5 (2)
M4
.8 (1.1) 1 (1.5) 2 (3) 3 (4.5) 4 (5)
M5
1.5 (2.5) 2 (3) 4.5 (6) 6.5 (9) 7.5 (10)
M6
3 (4) 4 (5.5) 7.5 (10) 11 (15) 13 (18)
M8
7 (9.5) 10 (13) 18 (25) 26 (35) 33 (45)
M10
14 (19) 18 (25) 37 (50) 55 (75) 63 (85)
M12
26 (35) 33 (45) 63 (85) 97 (130) 11 (150)
M14
37 (50) 55 (75) 103 (140) 151 (205) 177 (240)
M16
59 (80) 85 (115) 159 (215) 232 (315) 273 (370)
M18
81 (110) 118 (160) 225 (305) 321 (435) 376 (510)
