3
3.23
9924864 - 2012-2014 SPORTSMAN 800 / 6X6
© Copyright 2013 Polaris Sales Inc.
Engine Lubrication Specifications
Capacity - Approximately 2 U.S. Quarts (1.9 l)
Oil Type - Polaris PS4 2W/50 Synthetic
Filter Wrench - PV-43527 or equivalent
Oil Pressure Specification -
35-55 PSI @ 5500 RPM, Polaris 2W/50 Synthetic,
Engine at operating temperature.
Oil Pressure Test
1. Remove blind plug/sender from left side of
crankcase.
2. Insert a 1/4 NPTF oil pressure gauge adaptor into
the crankcase and attach the gauge.
3. Start engine and allow it to reach operating
temperature, monitoring gauge indicator.
NOTE: Use only Polaris PS4 2W/50 Synthetic
Engine Lubricant.
Oil Pressure at 5500 RPM (Engine Hot):
Maximum: 55 PSI
Minimum: 35 PSI
ENGINE
