9924864 - 2012-2014 SPORTSMAN 800 / 6X6
© Copyright 2013 Polaris Sales Inc.
Fan Motor Current Draw
A current draw test will provide a good indication of fan
motor condition. A worn or damaged fan motor will draw
more current, which causes a reduction in blade speed
and reduced cooling.
1. Disconnect the harness from the coolant sensor.
2. Connect a DC ammeter in between the fan switch
harness wires as shown.
3. Be sure fan blade is free to rotate.
4. Turn ignition key and engine stop switch to ON"
position. Read the current draw on ammeter with fan
running.
5. If the fan motor draws more than 15 Amps, replace
the motor.
Fan Motor Current Draw:
Should Be Less Than 15 Amps
NOTE: This fan motor current draw specification
only applies to Sportsman EFI models.
ELECTRICAL
