9924864 - 2012-2014 SPORTSMAN 800 / 6X6
© Copyright 2013 Polaris Sales Inc.
TRANSMISSION SERVICE (6X6)
Torque Specifications
COMPONENT
FT-LBS (IN-
LBS.)
NM
Transmission Case Bolts 27-34 37-46
Oil Deflector Screws
(16-30)
2-3.3
Shift Cover Bolt 6-12 8-16
Bell Crank Nut 12-18 16-24
Trans. Drain/Fill Plug
14 19
Trans. Mounting Bolts
25 34.5
Snorkel Lock Screw 8-12 11-16
Lubricant / Capacity
Use only Polaris recommended products if possible.
Specified Lubricant:
Polaris AGL Gearcase Lubricant
(Gallon - PN 2878069) (Quart - PN 2878068)
Capacity: 15 oz. (450 ml)
Fill Plug Torque:
14 ft-lbs (19 Nm)
Drain Plug Torque:
14 ft-lbs (19 Nm)
