LTE-A Module Series
EG060V-EA Hardware Design
EG060V-EA_Hardware_Design 12 / 82
2.2. Key Features
The following table describes the detailed features of the module.
Table 2: Key Features of EG060V-EA Module
Supply voltage: 3.3–4.3 V
Typical supply voltage: 3.8 V
Class 3 (24 dBm +1/-3 dB) for WCDMA bands
Class 3 (23 dBm ±2 dB) for LTE-FDD bands
1)
Class 3 (23 dBm ±2 dB) for LTE-TDD bands
Support up to Cat 6 FDD and TDD CA
Support uplink QPSK and 16QAM modulation
Support downlink QPSK, 16QAM and 64QAM modulation
Support 1.4 MHz to 40 MHz (DL 2×CA) RF bandwidth
Support 4 × 2, 2 × 2 MIMO in DL direction
FDD: Max 300 Mbps (DL)/50 Mbps (UL)
TDD: Max 220 Mbps (DL)/30 Mbps (UL)
Support 3GPP R7 HSPA+, HSDPA, HSUPA and WCDMA
Support QPSK, 16QAM and 64QAM modulation
HSDPA: Max 21 Mbps (DL)
2)
HSUPA: Max 5.76 Mbps (UL)
WCDMA: Max 384 kbps (DL)/384 kbps (UL)
Internet Protocol Features
Support PPP/TCP/UDP/FTP/HTTP/NTP/PING/HTTPS/SMTP*/
MMS*/FTPS/SMTPS*/SSL protocols
Support PAP and CHAP for PPP connections
Text and PDU mode
Point to point MO and MT
SMS cell broadcast
SMS storage: ME by default
Support (U)SIM card: 1.8/3.0 V
Support one digital audio interface: PCM interface
WCDMA: AMR/AMR-WB
LTE: AMR/AMR-WB
Support echo cancellation and noise suppression
Used for audio function with external codec
Support 16-bit linear data format
Support short frame synchronization
Support master and slave modes
To Next Page
