Page #19 background imageLoading...
Page #19 background image
LTE-A Module Series
EG060V-EA Hardware Design
EG060V-EA_Hardware_Design 18 / 82
3.3. Pin Description
The following tables define and describe the pins of the module.
Table 3: I/O Parameters Definition
Table 4: Pin Description
Type
Description
AI
Analog Input
AO
Analog Output
DI
Digital Input
DO
Digital Output
IO
Bidirectional
OD
Open Drain
PI
Power Input
PO
Power Output
Power Supply
Pin Name
Pin No.
I/O
Description
DC Characteristics
Comment
VBAT_BB
155,156
PI
Power supply for
the module’s
baseband part and
RF part
Vmax = 4.3 V
Vmin = 3.3 V
Vnorm = 3.8 V
It must be provided
with a sufficient current
of 1.5 A at least.
VBAT_RF
85, 86,
87, 88
PI
Power supply for
the module’s RF
part
Vmax = 4.3 V
Vmin = 3.3 V
Vnorm = 3.8 V
It must be provided
with a sufficient current
of 0.5 A at least
1)
.
VDD_EXT
168
PO
Provide 1.8 V for
external circuit
Vnorm = 1.8 V
I
O
max = 50 mA
Power supply for
external GPIO’s
pull-up circuits.
GND
10, 13, 16, 17, 24, 30, 31, 35, 39, 44, 45, 54, 55, 63, 64, 69, 70, 75, 76, 8184, 89, 90,
9294, 96100, 102106, 108112, 114, 116, 117, 118, 120126, 128133, 141, 142,
148, 153, 154, 157, 158, 167, 174, 177, 178, 181, 184, 187, 191,196, 202208,
214299
